KH3011A washer controller main controller for industrial washing machine laundry accessories

KH3011A controller also provides washer extractor with the following characteristics:

1.Relays are used as output components to control directly the driving components. This omission of intermediate relays conduces to less errors and easier maintenance and trouble shooting.

2.Timer operation selected under manual mode. 3.During automatic operation programmed time duration of an on-going step could be modified manually without stopping the operation.

4.During operation actual temperatures and set temperatures can be called to display at will. 5.Maximum extraction time limit were devised to prevent damage to textiles and machine parts due to excessive extraction.

6.Deal with unbalance under extracting status intelligently

7.Ajust the level at your option.

8.Various parameters integrated in the computer, which can be set up by manuafacturer before Exworks.
