IG5 IC5 high quality inverter frequency inverter of industrial factory laundry washing machine

Built-in communication interface and PC monitoring software

The iG5 has built-in the most popular communication interfaces such as Modbus-RTU and RS232/485. The iG5 has the small inverter features and standard medium drive features together. The "DriveviewTM" software offers Window® based computer monitoring tool through RS485 interface with graphic capture, keypad emulator, parameter edit and text monitor. It is applicable for all LG inverters.

Built-in PID control

It is valuable in process control. The built-in PID controller controls flow, temperature, pressure, etc. through the proportional, integral and differential calculus between the feedback value and reference value in closed loop.

IG5 inverter:	IG5-0.75kw IG5-1.5kw IG5-2.2kw IG5-4kw
Availability:

Quantity:



Inquire Add to Basket

Model:
IG5 IC5
Brand:
KEFALONG

Product Description

Product Description

洗脱机详情新_01

Built-in communication interface and PC monitoring software

The iG5 has built-in the most popular communication interfaces such as Modbus-RTU and RS232/485. The iG5 has the small inverter features and standard medium drive features together. The "DriveviewTM" software offers Window® based computer monitoring tool through RS485 interface with graphic capture, keypad emulator, parameter edit and text monitor. It is applicable for all LG inverters.

Built-in PID control

It is valuable in process control. The built-in PID controller controls flow, temperature, pressure, etc. through the proportional, integral and differential calculus between the feedback value and reference value in closed loop.
